Perfect for:

Flexible temporary solution for wheelchair access. It is the perfect solution for stages and mezzanine levels in schools, theatres, village halls and other public buildings. This compact lift with easy set-up and storage is available both for purchase and short- and long- term hire.

Highlights

This compact lift consists of a self-contained unit build on castors which can be wheeled into place with minimum effort and plugged into an existing power point. It folds down easily for transportation and storage. For short periods of use, built-in batteries provide up to 30 cycles between charges.

Standard Features

• Folds away for convenient moving and storage
• Large castors for easy transportation
• Shallow approach ramp for ease of access and egress
• Plug-in charger keeps batteries charged for immediate re-use
• Safety edge protection in both directions of travel
• Arrestor bar on platform for safety
• Scissor mechanism fully enclosed by bellows
• Low voltage operating system

Adding a personal touch

Optional extras include:

• Remote up/control kit
• External platform height adjustment
• Storage cover
• Outside use

Technical Specification

• Lift Size: Internal platform size: 1450 mm x 800 mm. Folded dimensions: 1210mm (h) x 600 mm (w) and 1530mm (l). A min. 150mm clearance around the lift is required once in position.
• Number of Floors: Maximum travel: 1000 mm
• Usage & Suitability: Ideal for stage/mezzanine access. Wheelchair users only.
• Technical Compliance: CE marked
• Load Capacity: 250 kg
• Installation: Two people required. Plugs into existing power point.
• Operation: Convenient controls
• Power Supply: 240 V, 13 A charger plugs into socket
• Drive System: Hydraulic scissor
• Speed: 0.06 m/sec
• Warranty: 12 months
